Ideal Hillmaster E609 E-MTB 29"

Name: Ideal Hillmaster E609 E-MTB 29"
Brand: IDEAL BIKES
SKU: IDEAL 29" HILLMASTER E609 E-MTB
Price: 1950 GBP
Availability: InStock

Reference: IDEAL 29" HILLMASTER E609 E-MTB

£1,950.00

IDEAL BIKES

Tax included

0 Review(s)

IDEAL E-Bikes are 100% certified by Hanse control Cert laboratory in Hamburg, Germany. Testing includes mechanical for frame and fork, mechanical dynamic (roller bench) or complete bike, electrical safety, electromagnetic compatibility, and chemical safety. HILLMASTER E609 is certified up to 120kg combined weight.

The IDEAL 29" Hillmaster is what you call a pure electric mountain bike, capable to tackle the hardest climbs and with a geometry that will make you feel comfortable even on the most technical descents on the trail.

Short rear centre of SHIMANO STEPS E6100 Drive Unit offers 60Nm for a more natural riding experience with 250W of power that allows riders to focus on the trail and enjoy the ride. Original Shimano battery integrates 504 Wh capacity providing range up to a 100 miles.

Ideal Hillmaster E609 E-MTB 29"

£1,950.00

IDEAL BIKES

Tax included

Size :

Colour :

Quantity :

This is an approximate conversion table to help you find your size.

If you already have purchased an item from our brand, we recommend that you select the same size as indicated on the table

Italian Size	French Size	Spanish Size	German Size	UK Size	USA Size	Japanese Size
34	30	30	30	4	00	34
36	32	32	32	6	0	36
38	34	34	34	8	2	38
40	36	36	36	10	4	40
42	38	38	38	12	6	42
44	40	40	40	14	8	44
46	42	42	42	16	10	46
48	44	44	44	18	12	48
50	46	46	46	20	14	50
52	48	48	48	22	16	52

Write review

Buy in one click

Security policy

All payment secured through encrypted networks.

Delivery policy

CFree delivery all over UK.

Return policy

Free return within 14 days.

IDEAL Hillmaster E609 Geometry

	Frame size	440	480	520	560
A	TOP TUBE	580	600.5	620	630
B	SEAT TUBE	440	480	520	560
C	REAR CENTER	450	450	450	450
D	WHEEL BASE	1086.2	1107.3	1127.5	1137.4
E	B.B. DROP	60	60	60	60
F	SEAT ANGLE	74°	74°	74°	74°
G	HEAD ANGLE	71°	71°	71°	71°
H	OFFSET	42	42	42	42
I	HEAD TUBE	110	120	130	140

SIZE CHART

size chart

Reference IDEAL 29" HILLMASTER E609 E-MTB

Data sheet

Frame: eHardtail 29,AL6061-T4/T6, Shimano STEPS, hydroforming, internal brake&gear cables
Size: 44/48/52 cm
Fork: RST Blaze-MLC, 100 mm, lockout, adjustable preload
Drive Unit: Shimano STEPS DU-E6100, 36V, 250W, 60Nm, sportiv
Battery: Shimano STEPS (down tube) BT-E8010, 36V, 14Ah, 504Wh
Display: Shimano STEPS SC-E6100
Rear Derailleur: Shimano Cues RD-U4000-GS
Shifter: Shimano STEPS SW-E7000 unit / gear lever switch // Shimano Acera SL-M3000
Crankset: Shimano STEPS FC-E6100, 38T
Cassette Sprocket: Shimano CS-LG300-9, CUES, 9-SPEED, 11-41T
Chain: Shimano CN-E6070-9
Front Hub: Shimano HB-TX505
Rear Hub: Shimano FH-TX505-8
Tires: Kenda 60-622 (29x2.35), K1153 30TPI
Brakes: Shimano BR-MT200 / BL-MT201 hydraulic disc brakes 180/180 mm
Handlebar: id-Project riser bar aluminum, 720 mm
Stem: id-Project aluminum, 31.8 mm
Seat Post: Id-Project, 31.6 mm
Saddle: Selle Italia X-BASE Boost
Rims: Mach1, 622-21
